Recently, I’ve been working on simplifying the Laverna CLI integration with Anki. What seemed challenging during the planning phase turned out to be elegant in execution. Here’s a summary of the challenges and takeaways.
The Original Workflow
Three months ago, I built an integration between Laverna CLI and Anki with this workflow:
- User downloads a custom Cloze note type (
note-type.apkg) from the repository and then imports to Anki (one-time setup) - User prepares CSV data in the expected format
- User runs Laverna CLI, which outputs enriched CSV
- User manually imports the CSV via Anki’s deck import tab
Everything looked normal on the surface, but steps 1 and 4 were cumbersome and repetitive. Since Anki doesn’t provide an official SDK or REST API, I needed to find another approach. Step 1 and 4 were also more error prone since it contained my internal app logic.
Discovery
While researching, I discovered Anki Connect which is an addon written as a single __init__.py file. Anki also has documentation on writing addons. It was quite readable way to interface with Anki.
Adding Python to a 100% pure Go repository felt strange, but I decided to build a proof of concept since there was no other way to do it. I have tried sqlite3 reverse engineering of Anki’s DB but it was strongly disencouraged way.
The constraint was clear: I had to use Anki’s bundled Python dependencies, which vary by Anki version. Looking at Anki Connect’s codebase, I noticed it used only standard library and no external dependencies which was very outdated but safe approach, it basically had to re-invent HTTPServer and HTTPClient via Unix sockets.
Fortunately, flask, waitress, request, and jsonschema were already available in Anki’s dependencies. I chose Flask (for HTTP abstractions) and Waitress (for the WSGI server) since I needed an endpoint to receive enriched CSV data and trigger Anki’s import functionality.
One another constraint was we could only run the addon code after Anki application started running. This meant that development workflow would need some sort of copy/paste or symlinking workflow which was not pretty but doable. Basically Anki addons were zipped __init__.py files which relied on Anki library and its dependencies and rarely vendored addon dependencies with no solid dependency hashes.
The Problem
Everything seemed fine until I hit an SQLite error:
# __init__.py
from flask import Flask, jsonify
from waitress import serve
import threading
from aqt import mw
app = Flask(__name__)
@app.route('/')
def hello():
note_count = mw.col.note_count() # RuntimeError: Cannot access collection from a background thread
return jsonify({'message': 'hello', 'notes': note_count})
def start_server():
serve(app, host='127.0.0.1', port=5000)
thread = threading.Thread(target=start_server, daemon=True)
thread.start()
The issue: Anki’s SQLite driver connection isn’t thread-safe. The collection object (mw.col) can only be accessed from Qt’s main thread. The documentation mentions this. Additionally, __init__.py can not block so we run HTTP server in deamon mode :)
The Solution
The solution was to use mw.taskman.run_on_main() to run queries on the main thread. But how do I collect the result and return it to my HTTP handler?
Check out Python’s Future a concept:
from concurrent.futures import Future
@app.route('/')
def hello():
future: Future = Future()
def get_count():
try:
count = mw.col.note_count()
future.set_result(count)
except Exception as e:
future.set_exception(e)
mw.taskman.run_on_main(get_count)
try:
note_count = future.result()
except Exception as e:
return jsonify({'error': str(e)}), 500
return jsonify({'message': 'hello', 'notes': note_count}), 200
This blocks until future.result() returns and handles exceptions.
Simplifying Further
I’m not a fan of try/catch boilerplate. After reading the note_count implementation, I decided to use tuples for error handling:
from concurrent.futures import Future
@app.route('/')
def hello() -> tuple[Response, HTTPStatus]:
future: Future = Future()
def get_count() -> None:
col = mw.col
if col is None:
return future.set_result((None, "Failed to load collection"))
count = col.note_count()
future.set_result((count, None))
mw.taskman.run_on_main(get_count)
(res, err) = future.result()
if err is not None:
return jsonify({"message": err}), HTTPStatus.INTERNAL_SERVER_ERROR
return jsonify({'message': 'hello', 'notes': res}), HTTPStatus.OK
This pattern might not be “Pythonic,” but it simplified everything beautifully.
Building the Full Logic
After the PoC worked, I implemented the complete solution (see PR):
- Validate the incoming request
- Perform Anki validations: create note type if missing, create deck if missing
- Read CSV and import via Anki functions (mostly protobuf types)
- Update Laverna CLI to POST directly to the addon’s endpoint instead of writing files
- Add flags and configuration options
The New Workflow
Starting with Laverna v0.3.0, the workflow is much smoother:
- User downloads Laverna Anki Addon from the official addon website (one-time setup)
- User prepares CSV data
- User runs Laverna CLI
❯ laverna anki --help
NAME:
laverna anki - Downloads audios to anki media folder and generates anki CSV file
USAGE:
laverna anki [options]
OPTIONS:
--profile string, -p string anki profile name
--deck string, -d string anki deck name
--endpoint URL, -e URL anki addon endpoint URL (default: "http://localhost:5555/v1/import-csv")
--speed SPEED, -s SPEED specify the SPEED of audios (default: "normal")
--voice VOICE, -v VOICE specify the VOICE of audios
--shuffle shuffles the text choices per row (default: true)
--strip-csv-header strips the csv header from the generated anki CSV file (default: true)
--stdout prints the generated anki CSV file to stdout (default: false)
--help, -h show help
GLOBAL OPTIONS:
--file FILE, -f FILE filepath to prompt FILE
--workers int, -w int maximum number of concurrent downloads (default: 16)
Example:
laverna anki --profile Talha --deck my-viet-deck --voice vi --file ./anki-vi-example.csv
Final
Happy new year to everyone!
